48V 5KW AC Motor Hunting Transport 6 Seater Golf Cart with Front Drum Rear Drum Brake System and Maximum Speed ≤30Km/h

48V 5KW AC Motor Hunting Transport 6 Seater Golf Cart with Front Drum Rear Drum Brake System and Maximum Speed ≤30Km/h

Price:	$1,980.00/pieces 1-19 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Brake System:

Front Drum+Rear Drum

Minimum Grand Clearance:

100-150mm

Curb Weight:

400-500kg

Maximum Speed:

≤30Km/h

Grade Ability:

10-15°

Driving Mileage:

≤30km

Standing Postion Of Tail Caddie:

Unequipped

Seats:

5 - 6

Speed:

15.5mph

Horsepower:

6.67hp

Product Description

ENJOY THE DRIVING

• New Front Design by R&D Team• Optional Two Sets of Configurations
• Strong Performance 48V5KW AC Motor
• Premium Brown Bolstered High-Back Seats
• Make OEM and ODM Design of New Golf Cart 4 Seater
When and wherever you need electric hunting buggy,
welcome to send enquiry to join our team, or learn more about our vehicles.

Specification

Model
Power		ELECTRIC	HP LITHIUM
	Motor/Engine	5KW(AC) KDS motor	5KW(AC) KDS motor
	Horsepower	6.67hp	6.67hp
	Batteries	Six, 8V150AH	48V 150AH Lithium-Ion (1)
	Charger	48V/25A	48V/25A
	Max. Speed	15.5mph(25khp)	15.5mph(25khp)
Steering & Suspension	Steering	Bidirectional rack and pinion steering system
	Front Suspension	Front: Macpherson independent suspension; Rear: Leaf spring and hydraulic shock absorber;
Brakes	Brakes	Rear wheel drum brake
	Park Brake	Electric parking
Brakes	Body&Finish	Front&Rear:Painted Injection moulding
	Tires	205/50-10(Tire diameter 18.1in) (460mm)
	LWH	145.053.282.7in (368013502100mm)
	Wheelbase	95.3in (2420mm )
	Ground Clearance	7.9in (200mm)
	Tread-Front and Rear	Front 34.7in (880mm) Rear 39.0in (990mm)
	Total Vehicle Weight	1276lbs(580kg)(including batteries) 616lbs(280kg) (without batteries)
	Frame Type	High strength carbon steel integral frame

Details Images

Product Introduction

PERFORMANCE FRONT SUSPENSION

Cengo electric hunting cart is built with McPherson independent suspension system, which is important part for the golf carts, you can see the drawing of ckds golf carts, which widely used in road vehicles, also our Cengo electric utility vehicle use this system, make sure it is durable and has strong road adaptability.

BEEFED UP TRANSAXLE

As best utility golf cart in this industry, Cengo use Integral rear axle which integrated pressure-die-casting aluminum gearbox housing and tightly sealed, due to the power is transmitted by mesh and involute teeth bevel gears, so when you drive and feel generate steady output torque, lower noise and better performance.

CURTIS CONTROLLER

Cengo controller system of golf utility vehicles are with two options for you, one of high configuration is Curtis controller, which mostly welcomed in the market, due to Charging protection and Anti Skipping regenerating braking, the system provide you with more safety redundancy downhill riding.

WATERPROOF WIRING HARNESS

Cengo custom 6 passenger golf cart supply the waterproof wiring harness IP67 and AMP connectors, which can prevent all the electronic components from the water and rainy weather, not easy to get short circuit, save the maintenance cost for you.

Cengo electric hunting buggy help you live larger and square shape looks more strong, big tire makes it has higher ground
clearance, ATV mud tire makes it more suitable for tough road. Increase your happiness during your hunting trave, so further customize the electric golf cart, following are 8 standard colors for your reference.

Features

Quick and efficient battery charge maximizes up-time. 2.New design storage compartment for the smart phone.
With speed control
system go downhill for safe and smooth.
High-strength steel pipe handrails and brackets are strong and reliable.
Inspired by automobiles, high lumen and low energy consumption LED lights.

Application

Passenger Transport built for the golf courses, hotels and resorts, schools, real estate and communities, airports, villas,railway stations and commercial establishments, etc.

Certifications

Company Introduce

Chengdu hongtaihengshun Science & Technology Co., Ltd located in ChengDu, is the earliest high-tech factory engaged in thedevelopment and manufacturer of electric vehicles in China, become one of the leading manufacturers ofelectric vehicles , owns 200,000 Sqm workshop, with more than 100 engineers/ technicians and more than1,000 skiled workers ,supply OED/0DM service and personal customization .The products range covers golfcarts, sightseeing buses, low-speed vehicles, hunting vehicles, multi-purpose vehicles etc.

our vehicles is subject to a strict NPl process lQC, POC and QA procedures and test 100% product inassembly line. international recognition of lS09001, EEC and CE certification is validated in our process.Through continuous breakthroughs in technology and optimization, hope our carts to go all over the world.

Remote technical support

In case of major situations, we can provide professional online guidance to solve problems. If it's necessary, we can send our team to local place.

1 year warranty for the major parts, 5 years warranty for lithium battery, except wearing parts, such as tires, etc.

Provide spare parts for free, during the warranty period.

1. What is your MOQ for electric golf buggy?

Each model has quantity limit, please advise the model you want, we will get back to you, and we accept OEM and ODM design,contact us for more.

2. What is your lead time for bulk golf cart supply?

As for the container order of golf carts, it is 15-30days after receiving the deposit payment. For more, please contact us
quickly.

3. Can we buy golf carts from golf cart dealers near me?

Yes, please leave your information and which model do you like, then we will ask our Cengo dealers of electric golf buggy in local market to contact you soon..
